Dimensions

Unit

Length: 8 1⁄16 in (20.5 cm)
Width: 6 ⅛ in (15.5 cm)
Height: 8 ⅜ in (21.4 cm)

Media Chamber

Length: 7 ⅜ in (18.9 cm)
Width: 2 9⁄16 in (6.6 cm)
Height: 5 ⅞ in (15 cm)

Wall Clearance

3 in (7.5 cm)

Tank Trim Clearance

1 in (2.6 cm)

Internal Tank Clearance

1 11⁄16 in (4.3 cm)

Technical Specifications

Aquarium Size

Up to 55 US gallons (200 Liters)

Flow Rate

250 US GPH (1000 L/H)

Watts

6 - (120 v - 60 Hz)
5 - (230 v - 50 Hz)

Filter Volume

0.32 US gallons (1.2 Liters)

Features at a Glance

• Reversible filter cover
• Maintenance alert device
• Overflow prevention
• Large-capacity filter basket
• Aerating return flow
• Flow regulation
• Intake flow regulation
• Surface skimmer
• Sub-surface intake
• Telescoping intake pipe
• Leveling dial
• Self-priming pump
• Self-cleaning impeller
• Heater holder

Package Contents

• Tidal 55 Filter
• Heater holder
• Telescoping intake pipe
• Leveling dial
• Foam filter
• Matrix™ bio-media
• Instruction Manual

Warranty Information

3 Year Warranty

All Tidal™ Filters are guaranteed against defects of materials and workmanship for a period of 3 years from the date of purchase, except for the pump’s impeller. This can be extended to 5 years by registering your filter.
